Cracked Ammonia Hydrogen Gas Generation Plant
A Cracked Ammonia Hydrogen Gas Generation Unit is an industrial system designed to produce a high-purity hydrogen-rich gas mixture by thermally cracking anhydrous ammonia (NH₃) using a nickel-based catalyst inside a controlled furnace. The process yields a gas composition containing approximately 75% Hydrogen (H₂) and 25% Nitrogen (N₂), making it a cost-effective and reliable alternative to pure hydrogen gas for applications in heat treatment furnaces, sintering, annealing, brazing, metal processing, powder metallurgy, electronics, and stainless-steel manufacturing. These units are widely used in industries looking for economical, safe, and consistent hydrogen generation without needing high-pressure storage cylinders.
High Hydrogen Output: Generates up to 75% Hydrogen with stable nitrogen dilution for reducing atmospheres.
Cost-Effective Hydrogen Source: Uses low-cost liquid or gaseous ammonia instead of expensive hydrogen cylinders.
Continuous Gas Supply: Designed for uninterrupted furnace operation with consistent pressure and flow rate.
Nickel Catalyst Reactor: Ensures efficient thermal cracking and long catalyst life.
Low Maintenance Design: Rugged construction with minimal wear components for reduced servicing cost.
Safety & Control Systems: Equipped with temperature controllers, flow meters, safety valves, and automation options.
Compact Footprint: Space-saving skid-mounted design suitable for modern industrial plants.
Customizable Capacity: Units available from small pilot scales to large industrial throughput.
Our Products
| Specification | Details |
|---|---|
| Furnace Type | Ammonia Cracking Furnace |
| Operating Temperature | 800°C – 1100°C (Customizable) |
| Ammonia Feed Capacity | 5 – 200 Nm³/hr (Customizable) |
| Product Gas | Hydrogen (75%) & Nitrogen (25%) |
| Heating Method | Electric |
| Catalyst Type | Nickel-based / Custom Catalyst |
| Material of Body Construction | MS/IS - 2062 |
| Inlet Ammonia Pressure | 1 – 10 Bar |
| Dew Point | -60°C |
| Purity | 98 - 99% |
